Engine General Information and Diagnosis: 1A-7
ECM Reception Data
Electronic Control System Description
S5JB0E1101011
The electronic control system consists of 1) various sensors which detect the state of engine and driving conditions, 2)
ECM which controls various devices according to the signals from the sensors and 3) various controlled devices.
Functionally, it is divided into the following sub systems:
• Fuel injection control system
• Ignition control system
• Intake manifold tuning valve control system (for J20 engine)
• Electric Throttle Body Control System
• Fuel pump control system
• Radiator cooling fan control system
• Evaporative emission control system (if equipped)
• EGR system
• A/F sensor heater control system (if equipped)
• Oxygen sensor heater control system (if equipped)
• A/C control system (if equipped with A/C)
• Camshaft position control system (for M16 engine)
• Immobilizer control system (if equipped)
• Generator control system (for J20 engine)
• Controller (computer) communication system
Especially, ECM (Engine Control Module), BCM (Body electrical Control Module), combination meter, TCM
(Transmission Control Module (For A/T model)), ABS / ESP® control module, 4WD control module (if equipped),
keyless start control module (if equipped) and steering angle sensor (for vehicle with ESP®) intercommunicate by
means of CAN (Controller Area Network) communication.
TCM
(for A/T model)
BCM
Torque reduction request
Slip control signal
Transmission malfunction
indication on
Transmission emissions related
malfunction active
Transmission gear selector
position
Daytime running light active
(if equipped with DRL)
Air conditioning switch ON
(if equipped with A/C)
A/T mode status
Electric load active (low beam)
Electric load active (high beam)
Electric load active (tail light)
Electric load active (rear defogger)
Blower fan step
Torque up request
Wheel speed pulse (rear right)
Wheel speed pulse (rear left)
Electronic stability program
system active
Electronic stability program
system off
Antilock brake system active
ABS hydraulic
unit/control module
assmbly (for vehicle
without ESP )
Receives data of ECM
ESP
control module
(for vehicle
with ESP )
R
R R
I5JB0D110002-02
