Lighting Systems: 9B-6
Turn Signal Light Switch (in Lighting Switch)
Inspection
S5JB0E9206012
Check for continuity between terminals at each switch
position. If check result is not as specified, replace
switch.
Headlight Manual Leveling Switch Inspection (If
Equipped)
S5JB0E9206021
Check for continuity between terminals at each switch
position.
If check result is not as specified, replace switch.
Illumination Cancel Switch Inspection (If
Equipped)
S5JB0E9206028
Check for continuity between terminals at each switch
position.
If check result is not as specified, replace switch.
[A]: Other than RH steering vehicle without rear fog light
[B]: RH steering vehicle without rear fog light
[C]: Terminal
[D]: Switch position
312
321 321
[C]
[D]
[A] [B]
N
N
I5JB0D920018-01
1
2
3
Switch Position
0
Terminal Resistance ( )
-
1
2
3
4
1 and 2
4370 - 4830
1 and 3
2 and 3
1 and 3
2 and 3
1 and 3
2 and 3
1 and 3
2 and 3
1 and 3
2 and 3
646 - 714
3724 - 4116
3078 - 3402
1292 - 1428
1938 - 2142
2584 - 2856
3230 - 3570
2432 - 2688
1786 - 1974
1140 - 1260
I4RS0B920012-01
1
2
3
4
Switch Position
Terminal
ON (PUSH IN)
12
3
4
OFF
I4RS0B920014-01
