4A-11 Brake Control System and Diagnosis:
Specifications
Tightening Torque Specifications
S5JB0E4107001
NOTE
The specified tightening torque is also described in the following.
“Front Brake Hose / Pipe Construction: ”
“Brake Booster Components: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fastener Information: in Section 0A in
related manual”.
Special Tools and Equipment
Special Tool
S5JB0E4108001
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Brake pipe flare nut for M10 16 1.6 12.0 ) / ) / )
Brake pipe flare nut for M12 19 1.9 14.0 ) / )
Master cylinder fixing nut 18 1.8 13.0 )
Booster attaching nut 13 1.3 9.5 )
09916–44310
Valve guide remover (5 mm)
) / )
To Next Page
