4F-33 Electronic Stability Program:
DTC Troubleshooting
DTC C1038: Steering Angle Sensor Detect Rolling Counter Failure from ESP® Control Module
S5JB0E4604034
DTC Detecting Condition and Trouble Area
DTC Troubleshooting
Step Action Yes No
1 Was “Electronic Stability Program Check” performed? Go to Step 2 Go to “Electronic
Stability Program
Check: ”.
2 Check steering angle sensor power supply circuit
1) Check circuit fuses for steering angle sensor and its
circuit.
Is it good condition?
Go to Step 3. Replace fuse and check
for short circuit to
ground.
3 Check steering angle sensor power supply circuit
1) Turn ignition switch to OFF position.
2) Disconnect steering angle sensor connector.
3) Check for proper connection to steering angle sensor
connector terminals at “E45-1”, “E45-2” and “E45-3”.
4) If OK, then measure voltage between connector terminal
“E45-3” and vehicle body ground.
Is it 10 – 14 V?
Go to Step 4. “WHT” wire circuit open.
4 Check steering angle sensor power supply circuit
1) Measure voltage between connector terminal “E45-1”
and vehicle body ground with ignition switch turned ON.
Is it 10 – 14 V?
Go to Step 5. “GRN/ORN” wire circuit
open.
5 Check steering angle sensor power supply circuit
1) Turn ignition switch to OFF position.
2) Measure resistance between connector terminal “E45-2”
and vehicle body ground.
Is resistance less than 2
Ω
?
Go to Step 6. “BLK” wire circuit open
or high resistance.
6 Check steering angle sensor
1) Connect steering angle sensor connector.
2) Check steering angle sensor referring to “Steering Angle
Sensor On-Vehicle Inspection: ”.
Is it good condition?
Substitute a known-
good ESP® hydraulic
unit / control module
assembly and recheck.
Replace steering angle
sensor.
DTC Detecting Condition Trouble Area
ESP® control module rolling counter failure is detected by
steering angle sensor.
• CAN communication circuit
• Steering angle sensor
• ESP® control module
Step Action Yes No
1 Was “Electronic Stability Program Check” performed? Go to Step 2. Go to “Electronic
Stability Program
Check: ”.
2 Check DTC
1) Connect scan tool to DLC with ignition switch turned
OFF.
2) Turn ignition switch ON and check DTC.
Is there any DTC(s) other than C1038 and C1090?
Go to applicable DTC
diag. flow.
Go to Step 3.
To Next Page
