Cruise Control System: 10A-3
Cancel Conditions of Cruise Control System
S5JB0EA101003
Constant cruising is cancelled under the following
conditions.
• *Ignition switch is turned OFF.
• MAIN (ON/OFF) switch is turned OFF.
• Vehicle speed becomes lower than minimum
operating speed (40 km/h (25 mile/h)).
• *Vehicle speed varies beyond cancel speed range (–
10 km/h (–6 mile/h)) from preset speed.
• *Brake pedal is depressed. (Brake light switch is
turned ON).
• *Clutch pedal is depressed (Clutch pedal position
switch is turned ON) (For M/T vehicle).
• *Selector lever is shifted to “P”, “R” or “N” range.
• *CANCEL switch is turned ON.
•*ESP® is operating (if equipped).
NOTE
When constant cruising is cancelled under
any condition with * (asterisk), vehicle speed
before cancellation can be resumed by
operating RES/ACC switch, provided that
vehicle speed is higher than 40 km/h (25 mile/
h).
Input / Output Diagram
S5JB0EA101004
Input Output
MAIN switch
Cruise control switch
RES/ACC switch
SET/COAST switch
CANCEL switch
CPP switch
(M/T model)
Stop (brake) lamp switch
Wheel speed sensor
ABS or ESP
control module
(vehicle speed signal)
ECM
Electric throttle body
(throttle valve control)
Combination meter
(Indicator lamp control)
TCM (Shift control)
(A/T model)
(A/T model)
Transmission range switch
( or range signal)
“P”, “R” “N”
I6JB01A10002-01
