Air Conditioning System: 7B-1
Air Conditioning System
General Description
Auto A/C Electronic Control Input / Output Table
S5JB0E7201003
Sunload sensor
Outside air temperature sensor
Evaporator temperature sensor
A/C refrigerant pressure sensor
Temperature selector
MODE (air flow) selector
Blower speed selector
Air intake selector
AUTO switch
A/C switch
Compressor relay
Blower motor controller
Temperature control actuator
Air flow control actuator
Air intake control actuator
BCM
ECM
Data link connector
HVAC control module
CPU
ECT sensor
Inside air temperature sensor
ABS control module or
ESP® control module
Wheel
speed
sensor
Radiator fan relay
*
*
I5JB0D720002-01
*: CAN communication
To Next Page
