About Tektronix oscilloscopes Product description
Parallel bus decoding, triggering and analysis
Serial bus decoding, triggering and analysis for SPI, RS-232/UART, 8b10B, MIPI, CAN, LIN,
FLEXRAY , MIL-1553, USB 2.0 and I
2
C buses are optionally available
MSO70000C Series Mixed Signal Oscilloscopes also offer:
16 digital channels plus 1 clock/qualifi
er channel
High resolution timing as precise as 80 ps
An analog view of any digital channel through the iCapture feature
Enhanced Logic Pattern and Logic State triggering includes digital channels
Differential (P6780) and single-ended (P6717A) logic probes
Easy connection to your device-under-test through the convenient design of the P6780 and the
P6717 Logic probes
iCapture allows analyzing the analog characteristics of the digital channels
MSO/DPO5000 Series instruments offer:
MagniVu 60.6 ps resolution
Signal process ing features
Waveform math. Set up math waveforms (see page 241) using the basic arithmetic functions,
including FFT, or create more advanced math waveforms using the math expression editor. Waveform
expressions can contain me asurement results and other math waveforms.
Spectral a nalysis. Display spectral magnitude and phase waveforms based on your time-domain
acquisitions. Control the instrument using the traditional spectrum analyzer controls
(see page 759),
such as span, c
enter frequency, and resolution bandwidth.
Mask testing.UseMask Testing (see page 782) for signal violation detection and pass/fail testing.
Test signals against a user defined mask, or with the Mask Testing Option
(see page 912),youcan
test against industry standard masks.
Display features
Color LCD display. Identify and differentiate waveforms (see page 168) easily with color coding.
Waveforms, readouts, and inputs are color matchedtoincreaseproductivity and reduce operating
errors.
Digital phosphor. The Digital Phosphor Oscilloscope can provide visual clues as to the relative rate
of occurrence of waveform features or anomalies by combining many separate acquisitions of a
waveform into a single intensity-graded or color-graded display.
Fit to screen. The Digital Phosphor technology performs the compression required to represent all
record points on the screen, even at the maximum record length settings.
MultiView Zoom. To take advantage of the full resolution of the instrument, you can zoom in on a
waveform (see page 724) to see fine details. Both vertical and horizontal zoom are available. You
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 3
