About Tektronix oscilloscopes Product description
can also zoom in on multiple areas of a single waveform simultaneously and on multiple waveforms
at the same time.
Measurement features
Cursors.Use
Cursors
(see page 82) to take simple voltage, time, and frequency measurements.
Automatic measurements. Choose from a large palette of amplitude, time, histogram, and
communicat
ion measurements. You can customize the measurements
(see page 724) by changing
reference levels or by adding measurement gating. Statistics (mean, maximum, minimum, standard
deviation and population) are available for each measurement value.
Trigger features
Simple and advanced trigger types. Choose a simple edge trigger or advanced trigger types (see
page 385) to help you capture a specific signal fault or event.
Dual triggers. Use the A (main) trigger system alone or add the B trigger to capture more complex
events. You can use the A and B triggers together
(see page 909) to set up a delay-by-time or
delay-by-events trigger condition.
Convenience features
Autos
et.UseAutoset
(see page 687) to quickly set up the vertical, horizontal, and trigger controls
for a usable display.
MySc
ope.UseMyScope
(see page 379) to create your own control windows for easy access to the
controls you use most often.
Tou
ch screen interface. You can operate all instrument functions (except the power switch) from the
touch screen interface
(see page 58). You can also install a mouse a nd keyboard.
To
olbarormenubar. You can choose a toolbar operating mode
(see page 32) that is optimized for
use with the touch screen, or a PC-style menu-bar operating mode
(see page 31) that is optimized
for use with a mouse.
Open desktop. The instrument is built on a Microsoft Windows software platform; the instrument
application program starts automatically when you apply power to the instrument. You can m inimize
the instrument application and take full advantage of the built-in PC to run other applications. Moving
waveform images and data into othe r applications is as simple as a copy/paste operation.
Dedicated front panel controls. The front panel contains knobs and buttons (see page 37) to provide
immediate access to the most common instrument controls. Separate vertical controls
(see page 60)
are provided for each channel. The same functions are also available through the screen interface.
Data storage and I/O. The instrument has a removable hard disk drive and a DVD/CD-RW drive that
can be used for storage and retrieval of data. The instrument has GPIB, USB, Ce ntronics (available
4 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
