Tektronix DPO70000C/DX Series User Manual

About Tektronix oscilloscopes Recommended accessories
TekProbe com ponent Description
P6015A 40 kVpk, 1000X, 75 MHz high voltage single-ended passive probe
TCPA300, TCPA400 Current measurement systems amplifier (requires TPA-BNC)
xxx
TekVPI
TekVP I component Description
TAP 1500
1.5 GHz active single-ended voltage probe
TAP 1500X2
Bundle of two 1.5 GHz TAP1500 active probes
TAP 2500
2.5 GHz active single-ended voltage probe
TCP0030 DC to 120 MHz, 30 A AC/DC current probe
TCP0150 DC to 20 MHz, 150 A AC/DC current probe
TDP0500
500 MHz active differential voltage probe
TDP1000
1 GHz active differential voltage probe
TPP500
, TPP1000
10X Pas
sive Probes are compact with 10X attenuation, designed
for use with Tektronix MSO/DPO4000B and MSO/DPO5000 Series
instruments.
The ba
ndwidth (–3 dB) for TPP500 is 500 MHz.
The bandwidth (–3 dB) for TPP1000 is 1 GHz.
xxx
DPO7000C
BNC
BNC component Description
CT1, CT2, CT6 Current probes, AC high-speed
P6021, P6022
Current probes, AC
xxx
TekProbe
TekProbe com ponent Description
ADA400A
Differential preamplifier
P5100A High-voltage probe
P6015A High-voltage probe
P6139B Passive probe
P6158
20X low-capacitance probe, 3 GHz
P6243
Active probe, 1 GHz
P6245
Active probe, 1.5 GHz
P6246
Differential probe, 400 MHz
P6247
Differential probe, 1 GHz
P6248
Differential probe, 1.5 GHz
P6701B
Converter, optical-to-electrical (multi-mode)
P6703B
Converter, optical-electrical (single-mode)
