D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
128
MLD Snooping Settings
Users can configure the settings for MLD snooping.
To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping
Settings, as shown below:
Figure 4-74 MLD Snooping Settings window (RI Mode Only)
Figure 4-75 MLD Snooping Settings window (EI and SI Mode Only)
The fields that can be configured are described below:
Parameter Description
MLD Snooping State
Click to enable or disable the MLD snooping state.
Max Learning Entry Value
(1-1024)
Enter the maximum learning entry value. (EI and SI Mode Only)
Click the Apply button to accept the changes made for each individual section.
Click the Edit button to configure the MLD Snooping Parameters Settings for a specific entry.
Click the Modify Router Port link to configure the MLD Snooping Router Port Settings for a specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Edit button, the following window will appear:
Figure 4-76 MLD Snooping Parameters Settings window (RI Mode Only)
