xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
459
the Disabled check box to disable the polling interval.
Click the Apply button to accept the changes made.
Click the Delete All button to remove all the entries listed.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
Ping Test
Ping is a small program that sends ICMP Echo packets to the IP address you specify. The destination node then
responds to or “echoes” the packets sent from the Switch. This is very useful to verify connectivity between the
Switch and other nodes on the network.
To view this window, click Monitoring > Ping Test as shown below:
Figure 11-25 Ping Test window
The user may click the Infinite times radio button, in the Repeat Pinging for field, which will tell the ping program to
keep sending ICMP Echo packets to the specified IP address until the program is stopped. The user may opt to
choose a specific number of times to ping the Target IP Address by clicking its radio button and entering a number
between 1 and 255.
The fields that can be configured are described below:
Parameter Description
Target IPv4 Address
Click and enter an IP address to be pinged.
Target IPv6 Address
Click and enter an IPv6 address to be pinged.
Interface Name
Enter the IP interface name to be pinged.
Domain Name
Click and enter the domain name of the host.
Repeat Pinging for
Enter the number of times desired to attempt to Ping either the IPv4 address or the
IPv6 address configured in this window. Users may enter a number of times between
1 and 255.
