xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
350
NOTE: A successful authentication should direct the client to the stated web page. If the client does
not reach this web page, yet does not receive a Fail! Message, the client will already be
authenticated and therefore should refresh the current browser window or attempt to open a
WAC User Settings
Users can view and set local database user accounts for Web authentication.
To view this window, click Security > Web-based Access Control (WAC) > WAC User Settings as shown below:
Figure 8-41 WAC User Settings window
The fields that can be configured are described below:
Parameter Description
User Name
Enter the user name of up to 15 alphanumeric characters of the guest wishing to
access the Web through this process. This field is for administrators who have selected
Local as their Web-based authenticator.
Click the button and enter a VLAN Name in this field.
Click the button and enter a VID in this field.
Password
Enter the password the administrator has chosen for the selected user. This field is
case-sensitive and must be a complete alphanumeric string. This field is for
administrators who have selected Local as their Web-based authenticator.
Retype the password entered in the previous field.
Click the Apply button to accept the changes made.
Click the Delete All button to remove all the entries listed.
Click the Edit VLAN Name button to re-configure the specific entry’s VLAN Name.
Click the Edit VID button to re-configure the specific entry’s VLAN ID.
Click the Clear VLAN button to remove the VLAN information from the specific entry.
Click the Delete button to remove the specific entry.
WAC Port Settings
Users can view and set port configurations for Web authentication.
To view this window, click Security > Web-based Access Control (WAC) > WAC Port Settings as shown below:
