xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
223
Parameter Description
Enter the IP interface name, used for this search, here.
Subscriber Source
Network Check
Click the Edit button and choose to enable or disable the flag that determines whether
or not to check the subscriber source IP when an IGMP report or leave message is
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the configure entries.
Click the Edit button to re-configure the specific entry.
IGMP Group Table
The window is used to display the dynamic IGMP groups on the Switch.
To view the following window, click L3 Features > IP Multicast Routing Protocol > IGMP > IGMP Group Table,
as shown below:
Figure 5-96 IGMP Group Table window
The fields that can be configured are described below:
Parameter Description
Enter the IP interface name used for this configuration.
Enter the multicast group IP address.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to view all the interfaces configured on this switch.
Click the View Detail link to view more information regarding the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Click the View Detail link to see the following window.
