xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
410
Figure 9-15 DHCP Server Manual Binding Window
The fields that can be configured are described below:
Parameter Description
Pool Name
Enter the DHCP Server Pool name.
IP Address
IP address which will be assigned to specified client.
Hardware Address
Enter the hardware address.
Type
Either Ethernet or IEEE802 can be specified.
Click the Add button to add a new entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the Delete button to remove the specific entry.
DHCP Server Dynamic Binding
This window is used to delete the DHCP server dynamic binding table.
To view this window, click Network Application > DHCP > DHCP Server > DHCP Server Dynamic Binding as
shown below:
Figure 9-16 DHCP Server Dynamic Binding Window
The fields that can be configured are described below:
Parameter Description
Pool Name
Enter the DHCP Server Pool name.
Click the Clear button to clear all the information entered in the fields.
Click the Clear All button to remove all the entries listed in the table.
DHCP Conflict IP
The DHCP server will use PING packet to determine whether an IP address is conflict with other host before
binding this IP. The IP address which has been identified conflict will be moved to the conflict IP database. The
system will not attempt to bind the IP address in the conflict IP database unless the user clears it from the conflict
IP database.
To view this window, click Network Application > DHCP > DHCP Server > DHCP Conflict IP as shown below:
