xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
367
Figure 8-60 Port Security VLAN Settings window
The fields that can be configured are described below:
Parameter Description
VLAN Name
Enter the VLAN Name.
VID List
Specify a list of the VLAN be VLAN ID.
Max Learning
Address
Specify the maximum number of port-security entries that can be learned by this
VLAN. Tick the No Limit check box to have unlimited number of port security entries
that can be learned by the VLAN.
Click the Apply button to accept the changes made.
Click the Edit button to re-configure the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Port Security Entries
Users can remove an entry from the port security entries learned by the Switch and entered into the forwarding
database.
To view this window, click Security > Port Security > Port Security Entries as shown below:
Figure 8-61 Port Security Entries window
The fields that can be configured or displayed are described below:
Parameter Description
VLAN Name
The VLAN Name of the entry in the forwarding database table that has been
permanently learned by the Switch.
VID List
The VLAN ID of the entry in the forwarding database table that has been permanently
learned by the Switch.
Port List
Enter the port number or list here to be used for the port security entry search. When
All is selected, all the ports configured will be displayed.
MAC Address
The MAC address of the entry in the forwarding database table that has been
permanently learned by the Switch.
