xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
471
Reset
The Reset function has several options when resetting the Switch. Some of the current configuration parameters
can be retained while resetting all other configuration parameters to their factory defaults.
NOTE: Only the Reset System option will enter the factory default parameters into the Switch's non-
volatile RAM, and then restart the Switch. All other options enter the factory defaults into the
current configuration, but do not save this configuration. Reset System will return the Switch's
configuration to the state it was when it left the factory
Reset gives the option of retaining the Switch's User Accounts and History Log while resetting all other
configuration parameters to their factory defaults. If the Switch is reset using this window, and Save Changes is
not executed, the Switch will return to the last saved configuration when rebooted.
Figure 12-16 Reset System window
The fields that can be configured are described below:
Parameter Description
Reset Selecting this option will factory reset the Switch but not the IP Address, User
Selecting this option will factory reset the Switch but not perform a Reboot.
Selecting this option will factory reset the Switch and perform a Reboot.
Click the Apply button to initiate the Reset action.
Reboot System
The following window is used to restart the Switch.
Figure 12-17 Reboot System Window
Selecting the Yes radio button will instruct the Switch to save the current configuration to non-volatile RAM before
restarting the Switch.
Selecting the No radio button instructs the Switch not to save the current configuration before restarting the Switch.
All of the configuration information entered from the last time Save Changes was executed will be lost.
Click the Reboot button to restart the Switch.
