xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
357
Figure 8-47 JWAC User Settings window
The fields that can be configured are described below:
Parameter Description
User Name
Enter the user name of up to 15 alphanumeric characters of the guest wishing to
access the Web through this process. This field is for administrators who have selected
Local as their Web-based authenticator.
Click the button and enter a VID in this field.
Password
Enter the password the administrator has chosen for the selected user. This field is
case-sensitive and must be a complete alphanumeric string. This field is for
administrators who have selected Local as their Web-based authenticator.
Retype the password entered in the previous field.
Click the Add button to add a new entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
JWAC Authentication State
This window is used to display Japanese web-based access control host table information.
To view this window, click Security > Japanese Web-based Access Control (JWAC) > JWAC Authentication
State as shown below:
Figure 8-48 JWAC Authentication State window
The fields that can be configured are described below:
Parameter Description
Port List
Enter the desired range of ports and tick the appropriate check box(s), Authenticated,
Authenticating, and Blocked.
Tick this check box to clear all authenticated users for a port.
Tick this check box to clear all authenticating users for a port.
Tick this check box to clear all blocked users for a port.
