xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
70
Figure 3-50 Web Settings window
The fields that can be configured are described below:
Parameter Description
Web Status
Web-based management is Enabled by default. If you choose to disable this by clicking
Disabled, you will lose the ability to configure the system through the web interface as soon
as these settings are applied.
Port (1-65535)
The TCP port number used for web-based management of the Switch. The “well-known”
TCP port for the Web protocol is 80.
Click the Apply button to accept the changes made.
Power Saving
LED State Settings
This window is used to configure the port LED state.
To view the following window, click Management > Power Saving > LED State Settings, as shown below:
Figure 3-51 LED State Settings window
The fields that can be configured are described below:
Parameter Description
LED State
Click the radio buttons to enable or disable the port LED state.
Click the Apply button to accept the changes made.
Power Saving Settings
This window allows the user to implement the Switch’s built-in power saving features and set the schedule to
enforce the settings.
To view the following window, click Management > Power Saving > Power Saving Settings, as shown below:
