xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
403
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay VLAN Settings as shown
below:
Figure 9-5 DHCP Relay VLAN Settings window
The fields that can be configured are described below:
Parameter Description
Enter the VLAN ID list used for this configuration here.
Enter the DHCP/BOOTP server IP address used here.
Click the Add button to add an entry.
Click the Delete button to remove an entry.
DHCP Relay Option 60 Server Settings
This window is used to configure the DHCP relay Option 60 server parameters.
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 60 Server
Settings as shown below:
Figure 9-6 DHCP Relay Option 60 Server Settings window
The fields that can be configured are described below:
Parameter Description
Enter the DHCP Relay Option 60 Server Relay IP Address.
Use the drop-down menu to select the DHCP Relay Option 60 Server mode.
Click the Add button to add a new entry based on the information entered.
Click the Apply button to accept the changes made.
Click the Delete button to remove the specific entry.
Click the Delete All button to remove all the entries listed.
NOTE: When there is no matching server found for the packet based on Option 60, the relay servers
will be determined by the default relay server setting.
DHCP Relay Option 60 Settings
This option decides whether the DHCP Relay will process the DHCP Option 60 or not
To Next Page
