D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
72
Parameter Description
Action
Use the drop down menu to add or delete the schedule.
Time Range Name
Specify the name of the schedule.
Click the Apply button to accept the changes made for each individual section.
Click the Clear Time Range to remove all the entries.
Power Saving Port Settings
This window is used to set the power saving state.
To view the following window, click Management > Power Saving > Power Saving Port Settings, as shown
below:
Figure 3-54 Power Saving Port Settings
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit you wish to configure. (EI and SI Mode Only)
From Port / To Port
Select the appropriate port range used for the configuration.
Action
Use the drop down menu to add or delete the schedule.
Time Range Name
Specify the name of the schedule.
Click the Apply button to accept the changes made for each individual section.
Click the Clear Time Range to remove all the entries.
SD Card Management
SD Card Backup Settings
This window is used to create a schedule to back up the configuration or log to file system.
To view the following window, click Management > SD Card Management > SD Card Backup Settings, as
shown below:
Figure 3-55 SD Card Backup Settings window
The fields that can be configured are described below:
