D-Link xStack DGS-3120 Series Reference Guide

xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
154
Figure 4-114 LLDP Basic TLVs Settings window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit you want to configure. (EI and SI Mode Only)
From Port / To Port
Select the port range to use for this configuration.
Port Description
Use the drop-down menu to enable or disable the Port Description option.
System Name
Use the drop-down menu to enable or disable the System Name option.
System Description
Use the drop-down menu to enable or disable the System Description option.
System Capabilities
Use the drop-down menu to enable or disable the System Capabilities option.
Click the Apply button to accept the changes made.
LLDP Dot1 TLVs Settings
LLDP Dot1 TLVs are organizationally specific TLVs which are defined in IEEE 802.1 and used to configure an
individual port or group of ports to exclude one or more of the IEEE 802.1 organizational port VLAN ID TLV data
types from outbound LLDP advertisements.
To view the following window, click L2 Features > LLDP > LLDP > LLDP Dot1 TLVs Settings, as shown below:
