breaker on the SmartLi where the BCU blinks at super short intervals one by
one.
----End
5.1.2 Commissioning the Power Supply and Distribution
System in the Integrated PDF Scenario
Context
The IT route of the integrated PDF is powered by the UPS outside the smart
module.
Tool: multimeter
Procedure
Step 1 Switch on all SPD circuit breakers in the integrated PDF.
Step 2 Switch on the upstream mains input circuit breaker (outside the smart module)
for the integrated PDF to power on the smart cooling product route of the
integrated PDF.
If the smart cooling product power indicator on the front panel of the integrated PDF lights up,
the smart cooling product route of the integrated PDF is powered on properly.
Step 3 Check that the voltage and frequency are within the normal ranges.
● Measure the line voltage at the customer input side using a multimeter. The line voltage
should be in the range of 342–456 V.
● Measure the frequency at the customer input side using a multimeter. In the 50 Hz scenario,
the frequency should be in the range of 47–53 Hz. In the 60 Hz scenario, the frequency
should be in the range of 57-63 Hz.
Step 4 Switch on the upstream input circuit breaker (UPS output circuit breaker outside
the smart module) for the integrated PDF to power on the IT equipment route for
the integrated PDF.
If the IT power indicator on the front panel of the integrated PDF lights up, the IT equipment
route for the integrated PDF is powered on properly.
Step 5 Wait about 2 to 3 minutes until the MDU screen starts. Then log in to the system.
