Table 5-22 Function commissioning
Check Method Normal Connection Status Alarm Clearance Method
Simulate a
smoky
environment
under the smoke
detector.
Smoke DI alarm is displayed
on the active alarm page of
the app or WebUI.
Disconnect the smoke
detector cable and reconnect
it to clear the alarm.
----End
5.3.10.2 Commissioning a WLD900 Water Sensor
If a water sensor is installed, perform the following steps to congure it.
Prerequisites
One end of the straight-through cable has been connected to the RJ45 port on the
WLDS900 water sensor, and the other end has been connected to the AI/DI_2 port
on the ECC800-Pro.
Context
● To use the AI/DI sensor, enable the corresponding AI/DI port and name the
sensor. The
specic alarm then can be reported.
● If the sensor is preinstalled, only check its settings.
● The actual value may vary. Only the method of the parameter settings is
described.
Procedure
Step 1 Set water sensor parameters.
The default alarm severity of the AI/DI port is Minor. If you want to change the alarm
severity, see How Should I Congure Alarm Parameters.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose System Settings > Signal Name Modify. The Batch Signal
Conguration page is displayed.
3. Set Device type to ECC800, set Device name to ECC800, and click OK.
4. On the query result tab page, set the new signal name of AI/DI_2 to Leak
and click Submit.
5. Choose Monitoring > System > ECC800 > Running Parameters > AI/DI_2
Port Settings.
6. Set Leak sensor to Enable and click Submit.
7. Conrm that Leak sensor type is automatically identied as Leak
sensor(Rope).
8. Click Unhide All Advanced Signals, then click Power Supply Parameters.
Ensure that I power supply enable(AIDI_2/COM1/AIDI_4/COM3) is Enable.
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 199
