3.5.1.4 (Optional) Installing a Vertical Ground Bar
Context
Install the vertical ground bar in the IT cabinet closest to the PDF.
Preparations
Tool: Phillips screwdriver
Material: vertical ground bar
Procedure
Step 1 Open the cabinet rear door and use four M4 screws to secure the vertical ground
bar to the right mounting bar.
The specic securing positions are the screw holes in the middle of the 04 U, 14 U, 29 U, and 39
U positions.
FusionModule2000-S Smart Modular Data Center
User Manual 3 Hardware Installation
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 56
