Application Scenario Screw Specications Torque (N·m) (Tolerance:
±10%)
M16 screw assembly 35
Cord end terminals M2 0.22–0.25
M2.5 0.5–0.6
M3 0.6–0.8
M3.5 0.8–1.6
M4 1.5–1.8
M5 2.5–3.0
M6 3.2–3.7
7.5 Installation Verication
Cabinet Installation Checklist
No.
Check Item Check Result
1 The cabinets are placed according to the
equipment room layout diagram.
□ Passed □ Failed
2 The height deviation of all cabinets and the depth
deviation of adjacent cabinets are less than 5 mm.
□ Passed □ Failed
3 All bolts and screws are rmly tightened,
especially on electrical connections. Flat and
spring washers are used with each bolt, and
spring washers are placed on the top of at
washers.
□ Passed □ Failed
4 The cabinets are clean and meet dustproof
requirements.
□ Passed □ Failed
5 The paint on the cabinet exterior is intact. If paint
akes o, repaint that area immediately to avoid
corrosion.
□ Passed □ Failed
6 The cabinet doors and locks work properly. □ Passed □ Failed
7 All labels are correct, clear, and complete. □ Passed □ Failed
8 There is no foreign matter such as adhesive tape,
cable ties, paper, or packing materials left around
the cabinets.
□ Passed □ Failed
9 The cabinet ller panels are adjusted to ensure
that the cold aisle and hot aisle are isolated.
□ Passed □ Failed
FusionModule2000-S Smart Modular Data Center
User Manual 7 Appendix
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 331
