3.1.3 Moving the PDF
Context
● Only trained personnel are allowed to move the PDF. Use a forklift truck to
transport the PDF box secured to a wooden support to the installation position.
● To prevent the PDF from falling over, secure the PDF box to the forklift truck
using ropes before moving it.
● Move the PDF with caution to avoid bumping or toppling, which may damage
the PDF. After placing the PDF in the installation position, unpack it with care
to avoid scratches. Keep the PDF steady during unpacking.
● If the PDF installation environment is in poor condition and the PDF needs to
be stored for a long time after it is unpacked, take measures to prevent dust. It
is recommended that the PDF be wrapped with the original plastic coat.
Preparations
Tools: forklift truck, adjustable wrench, diagonal pliers
Materials: PDF and accessories, sliding plate
Document: cabinet layout diagram
Skill requirement: forklift driver, common technician
Procedure
Step 1 Check whether the PDF packing is intact.
Step 2 Cut
o and remove the binding straps, and remove the packing.
Step 3 Remove the plastic bag and take out the tting box and sliding plates.
Step 4 Check whether the PDF is intact.
1. Check the exterior of the PDF and check whether the PDF is damaged during
transportation. If any damage is found, notify the carrier immediately.
2. Check that the
ttings comply with the packing list. If some ttings are
missing or do not comply with the packing list, record the information and
contact your local Huawei
oce immediately.
Step 5 After verifying that the PDF is intact, remove the L-shaped brackets securing the
cabinet and pallet, and insert the two sliding plates under the pallet.
Ensure that the sliding plates are properly installed in step (2) in Figure 3-1; otherwise, the
sliding plates may shift when the PDF is unloaded.
FusionModule2000-S Smart Modular Data Center
User Manual 3 Hardware Installation
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 37
