● When switching on an output circuit breaker, check whether the mapping between the
circuit breaker and the downstream device is consistent with that in the design drawing.
● Do not switch on the reserved circuit breakers.
● When switching on the circuit breakers, observe whether there is any abnormal
phenomenon, such as sparks or unsmooth switching.
Step 7 The Branch Disconnected alarm generated for a reserved circuit breaker can be
masked on the ECC800-Pro WebUI. To mask an alarm, choose System Settings >
Alarm Parameters, select the corresponding device, and disable the
corresponding Branch Disconnected alarm parameter.
----End
5.1.5 Commissioning a Smart rPDU
Prerequisites
One end of the straight-through cable has been connected to the COM port on
the rPDU and the other end has been connected to the COM port on the ECC800-
Pro or ETH converter.
Context
Table 5-11 rPDU basic information
Model
Name
Displayed on
the WebUI
Output
Port
Eleventh and
Twelfth
Characters in
Device
Barcode
a
BOM
Number
PDU2000-32-1P
H-20/4-M1
PDU2000-M(C) 20 x C13
+ 4 x C19
FT 2120701
PDU2000-32-1P
H-20/4-M1
PDU2000-M(H) 20 x C13
+ 4 x C19
6B 2120701
MD-1324-2004 rPDU-MPDU 20 x C13
+ 4 x C19
FT 2122280
PDU2000-16-3P
H-24/6-M1
PDU2000-
MH-3PH
24 x C13
+ 6 x C19
6B 2120624
PDU2000-16-3P
H-24/6-M1
PDU2000-
MC-3PH
24 x C13
+ 6 x C19
FT 2120624
PN1-32I10-20E4
G-AV4
rPDU
20 x C13
+ 4 x C19
6B 2122201
ZFIF-112-0800 8 x C13 FT 2123125
PN1-16X18-8E-
AH4W
8 x C13 6B 2122935
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 150
