Figure 3-14 Leveling a smart cooling product cabinet
(1) Level
Step 4 Level other cabinets in the same way.
----End
3.4 Combining Cabinets
Procedure
Step 1 Level the cabinets using a wrench.
● Use a measuring tape to check that the vertical distance between the top of
the 2000 mm high cabinet and the oor is 2000 mm (±3 mm). Then use a level
to check that the cabinet is level.
● If the leveled height of a cabinet does not meet the requirement, the door of
the cabinet behind it may not be opened or closed properly.
● Adjust the base height or use washers to level the IT equipment.
FusionModule2000-S Smart Modular Data Center
User Manual 3 Hardware Installation
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 49
