Huawei FusionModule2000-S User Manual

Maintenanc
e Item
Method Expected Result Troubleshooting
LAN switch
availability
Observe the PWR
indicator on the
LAN switch.
Observe the SYS
indicator on the
LAN switch.
The PWR indicator
is steady green.
The SYS indicators
are blinking green.
Take corrective
measures based on
the PWR indicator
status:
● O: The PSU is
not detected, or
the board power
supply is abnormal
when the LAN
switch is
congured with
one PSU.
● Steady red. The
possible causes are
as follows:
The two PSUs for
the LAN switch are
installed but not
powered on.
The power supply
is disconnected.
Both the board
power supply and
PoE power supply
are faulty.
● Steady orange:
When the LAN
switch is
congured with
one PSU, the PoE
power supply is
abnormal. If the
LAN switch is
congured with
two PSUs, the
board power
supply or PoE
power supply is
abnormal.
Take corrective
measures based on
the SYS indicator
status:
●
O: The LAN
switch is not
operating.
FusionModule2000-S Smart Modular Data Center
User Manual 6 Operation and Maintenance
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 290
