Troubleshooting

C300 5-7

Troubleshooting Chapter 5

Paper misfeed indications

No. Description

1 A paper misfeed in the ADF (transport section) (p. 5-37)

2 A paper misfeed in the ADF (scanning section) (p. 5-41)

3 A paper misfeed in the ADF (feed section) (p. 5-33)

4 A paper misfeed in the ADF (output section) (p. 5-46)

5 A paper misfeed in the ADF (turnover section) (p. 5-49)

6 A paper misfeed in the fusing unit (p. 5-23)

7 A paper misfeed in the main unit (p. 5-19)

8 A paper misfeed in the bypass tray (p. 5-8)

9 A paper misfeed in the LCT (p. 5-17)

10 A paper misfeed in the saddle stitcher (p. 5-58)
