5
Troubleshooting
5-58
C300
Troubleshoot
ing
Chapter 5
To clear a paper misfeed in the saddle stitcher
1
Open the
front door.
2
Turn dial FN5 or dial
FN6
to feed out the paper.
3
Remove
all paper from
the finishing tray.
FN6
FN5
312
314
