Troubleshooting

5-64 C300

Troubleshooting Chapter 5

5.6 When the message “Need to replace XXXX.” appears

When it is time to replace supplies or a part within this machine, a message

similar to the one shown below appears, indicating that the part or supplies

should be replaced, and the machine stops operating.

Display in Enlarge Display mode

Touch to display the message shown in the following illustration.
