Installation and operation precautions

1-16 C300

Installation and operation precautions Chapter 1

1.4 Space requirements

To ensure that machine operation, consumables replenishing, part replace-

ment, and regular maintenance can easily be performed, adhere to the rec-

ommended space requirements detailed below.

Reminder

Be sure to allow a clearance of 100 mm (4 in.) or more at the back of this

machine for the ventilation duct.

Unit: mm (inch)

C300+DF-608+FS-514+

PC-403+SD-503+OT-601

190

(7-1/2)

1212

(47-3/4)

341

(13-1/2)

394

(15-1/2)

755

(29-3/4)

100

(4)

372

(14-3/4)

1208 (47-1/2)
