SECTION 10 - ENGINE
10-86
Replace the in-line filter, 1, every 250 hours of
operation. To remove the filter, remove the two hose
clamps, 2, and remove the hoses from the filter.
Install a new filter, hoses, clamps and tighten.
WARNING
All service should be performed with the engine
shut down. If servicing the loader with the boom
in the raised position, be sure the boom arms are
supported by the boom lock pins.
145
PRIMING THE FUEL SYSTEM
The skid steer loader is equipped with an electric fuel
pump, 1. If the engine has been run out of fuel, add
a minimum of 5 gallons (18.9 L) fuel to the tank.
146
Put the Service/Run switch, 1, in the SERVICE
position. Remove the fuel line, 2, Figure 148, at the
injector pump.
Turn the ignition switch to the RUN position and allow
the electric fuel pump to pump fuel until a full stream
of fuel (no air) flows at 2, Figure 148. Reinstall the fuel
line. Now start the engine and allow the engine to run
until the injection pump self bleeds the air from the
pump.
19984337
1
147
