SECTION 55 - ELECTRICAL SYSTEM
55-25
15
CONTINUOUSLY MONITORED ELEMENTS
The following machine elements are continuously
monitored by the EIC:
1. Engine air filter.
Monitors the condition of the air cleaner element
and will signal when the element is dirty and
requires replacement.
2. Hydraulic oil filter.
Monitors the condition of the filter and will signal
when the filter is dirty and requires replacement.
3. Engine coolant temperature.
When the engine coolant temperature is above
operating temperature of 102°C (216°F), the
lamp will flash with a 5-second alarm.
4. Battery Voltage.
When battery voltage drops below normal
voltage the lamp will flash with a 5-second alarm.
5. Hydrostatic charge pressure.
When the pressure drops below normal
operating pressure the lamp will flash with a
continuous alarm.
6. Engine oil pressure.
When the engine oil pressure drops below
normal pressure the lamp will flash with a
continuous alarm.
7. Transmission/Hydraulic oil temperature.
When the oil temperature is above operating
temperature of 99°C (210°F), the lamp will flash
with a 5-second alarm.
Whenever the EIC senses any unusual condition
in a monitored function, the associated lamp will
flash. The audible alarm will “beep” continuously
for 5 seconds.
