SECTION 00 - GENERAL INFORMATION
00-20
3. Jack up the skid steer and block it securely with
all four wheels off the ground, as shown. Position
the front blocks, 1, to the front of the final drive
housings and the rear blocks, 2, to the rear of the
flat area of the final drive housings.
WARNING
Never attempt to tilt the skid steer cab over
unless the skid steer is securely supported.
20
4. Open the rear door, 1. Raise the top engine
shield, 2, and latch in the raised position.
5. Remove engine side covers, 3.
21
6. Disconnect the battery negative (-) cable, 1.
22
