SECTION 29 - HYDROSTATIC TRANSMISSION
29-35
18. Remove the trunnion bearing cover, 1, and
support bracket, 2, by removing the three
capscrews, 3. Pry the cover off by inserting
screwdrivers in the notches on the side of the
cover.
19997800
2
1
3
3
50
19. Remove the O ring, 1, and discard. The tapered
bearing, 2, and the bearing race, 3, on this side
are press fit and are not removed unless
damaged.
19997801
2
1
3
51
20. Remove the control arm side bearing cover, 1, by
removing the three capscrews, 2. Pry the cover
off by inserting screwdrivers in the notches on the
side of the cover.
19997802
1
2
52
To Next Page
