9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
3.27
26.Connect the battery. Torque fasteners to
specification.
TORQUE
Battery Terminal Fasteners:
40 in-lbs (5 Nm)
ENGINE INSTALLATION (HVAC)
1. Complete Engine Installation, page 3.24.
2. Install both coolant hoses onto the water pump. Install
clamp
q
and
w
. Torque clamp
w
to specification.
TORQUE
Coolant hose clamp:
35 in-lbs (4 Nm)
3. Attach coolant hose to oil cooler and install clamp
e
.
4. Install orange alternator hot wire and torque fastening
nut to specification.
TORQUE
Alternator wire to Terminal Block:
3.3 ft-lbs (4 Nm)
5. Connect both AC lines to the compressor. Torque AC
lines to specification.
TORQUE
AC lines at compressor:
18 ft-lbs (24 Nm)
6. Reinstall the battery cover and flip down the
passenger seat.
7. Fill coolant reservoir. Bleed system as required. See
Cooling System Bleeding Procedure, page 3.91.
8. Check and fill engine oil as required. See Engine Oil
and Filter Replacement, page 2.34.
9. Connect the battery. Torque fasteners to
specification.
ENGINE / COOLING / EXHAUST
