10.36
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
9. Remove the T-40 torx fasteners
i
. Lift and remove
the driver’s floor from the vehicle.
FLOOR INSTALLATION
1. Install the driver’s floor and the T-40 torx fasteners
q
.
Torque to specification.
TORQUE
Body Fasteners:
42 in-lbs (5 Nm)
2. Install the push rivets
w
and the T-40 torx fasteners
e
. Torque to specification.
TORQUE
Body Fasteners:
42 in-lbs (5 Nm)
3. Install the passenger floor. Install the push rivets
r
and the T-40 torx fasteners. Torque to specification.
TORQUE
Body Fasteners:
42 in-lbs (5 Nm)
BODY / FRAME
