6.2
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION - TRANSMISSION
SERVICE NOTES - TRANSMISSION
CAUTION
Serious injury may result if machine tips or falls. Be
sure machine is secure before beginning any procedure
that requires machine lifting. Always wear eye
protection.
The transmission has two traction operational modes:
Differential Lock and Differential Unlock. Locking the rear
differential is beneficial in low traction and rough terrain
conditions. Unlocking the rear differential makes
maneuvering easier and minimizes damage to terrain.
SPECIAL TOOLS - TRANSMISSION
PART
NUMBER
TOOL DESCRIPTION
PU-52547 Snorkel Tube Tool
2871699 Rear Driveshaft Seal Guide
2871698
Rear Output Seal Driver
2871282
Bearing Seal Driver (50 mm)
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com
SERVICE SPECIFICATIONS -
TRANSMISSION
FLUID CAPACITY
Recommended Transmission Lubricant: AGL
(PN: 2878068) (Quart)
Capacity: 44 oz. (1300 ml)
TRANSMISSION
