2
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
2.43
EXHAUST SPARK ARRESTOR INSPECTION
WARNING
Do not clean spark arrestor immediately after the
engine has been run, as the exhaust system becomes
very hot. Serious burns could result from contact with
the exhaust components. Allow components to cool
sufficiently before proceeding. Wear eye protection and
gloves.
Never run the engine in an enclosed area. Exhaust
contains poisonous carbon monoxide gas that can
cause loss of consciousnessor death in a very short
time.
Periodically clean spark arrestor to remove accumulated
carbon.
1. Remove the retaining screw
q
and nut
w
.
2. Remove the spark arrestor
e
from the end of the
silencer
r
.
3. Use a non-synthetic brush to clean the arrestor
screen. A synthetic brush may melt if components are
warm. If necessary, blow debris from screen with
compressed air.
4. Inspect the screen for wear and damage. Replace if
needed.
5. Reinstall the arrestor and torque the retaining screw
to specification.
TORQUE
Spark Arrestor:
8 ft-lbs (11 Nm)
MAINTENANCE
