SERVICE SPECIFICATIONS - PVT SYSTEM
PART
DESCRIPTION
SERVICE
SPECIFICATION
SERVICE
LIMIT
Drive Clutch
Spring Part
Number
7044697
—
Drive Clutch
Spring Color
Black
—
Drive Clutch
Spring Free
Length
3.76 in (95.43
mm)
EBS Spring Free
Length
0.76 in (17.78
mm)
—
Drive Clutch
Button to Tower
Clearance
000-.010” 0.020” (0.508
mm)
Drive Clutch
Shaft Diameter
1.413” (35.913
mm)
1.416”
(35.975 mm)
Flange Sleeve
Shaft Diameter
1.693” (42.98
mm)
1.692”
(42.993 mm)
Vespel® Thrust
Washer
Thickness
0.030 – 0.040”
(0.76 - 0.96 mm)
0.020” (0.50
mm)
Drive Clutch Helix
Thickness
Greater than
0.146” (3.71 mm)
0.146” (3.71
mm)
CLUTCH CHART
CLUTCHES
ALTITUDE
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
0-1800 Meters
(0-6000 Feet)
32–106
(1323458)
Black
(7044938)
7044761
1800-3700
Meters
(6000 - 12000
Feet)
32–97
(1323520)
Black
(7044938)
7044761
PVT SYSTEM
