2.40
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
CAUTION
Never remove the pressure cap when the engine is
warm or hot. Escaping steam can cause severe burns.
The engine must be cool before removing the pressure
cap.
5. Remove the pressure cap. Using a funnel, add
coolant to the top of the radiator filler neck.
6. Reinstall the pressure cap.
NOTE
Use of a non-standard pressure cap will not allow the
recovery system to function properly.
7. Remove the recovery bottle cap and add coolant
using a funnel.
8. Fill the recovery bottle to the “MAX” mark with the
recommended pre-mix coolant. You may use a 50/50
or 60/40 mixture of antifreeze and distilled water as
required for freeze protection in your area.
FLUID CAPACITY
Recommended Anti-Freeze/Coolant:
Premium Pre-Mixed Extended Life Antifreeze
(PN 2880514) (Quart)
(PN 2880513) (Gallon)
9. Reinstall the recovery bottle cap.
10.If coolant was required, start engine and check for
leaks. Make sure radiator fins are clean to prevent
overheating.
COOLING SYSTEM HOSE INSPECTION
1. Inspect all vehicle hoses for cracks, deterioration,
abrasion or leaks. Replace if necessary.
2. Inspect all engine hoses for cracks, deterioration,
abrasion or leaks. Replace if necessary.
3. Check tightness and condition of all hose clamps. Do
not over-tighten hose clamps at radiator, or radiator
fitting may distort.
TORQUE
Coolant Hose Clamp:
35 in-lbs (4 Nm)
MAINTENANCE
