9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
11.5
SPECIAL TOOLS - ELECTRICAL
TOOL DESCRIPTION
PART
NUMBER
Fluke™ 77 Digital Multimeter
PV-43568
Static Timing Light Harness
2871745
Hall Effect Sensor Probe Harness 2460761
Battery Conductance Analyzer
(MDX-610P)
PU-50296
Connector Test Kit PV-43526
Timing Light
2870630
Relay Bypass
PU-49466
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
SERVICE SPECIFICATIONS - ELECTRICAL
PART DESCRIPTION
SERVICE
SPECIFICATION
Seat Belt Switch Normally Open
Drive Mode Switch -
Performance
4750 Ω
Drive Mode Switch -
Standard
25,000 Ω
Drive Mode Switch - Work 1600 Ω
AWD Hub Coil Resistance 24 Ω ± 5%
Fuel Sender Resistance -
Empty
90 ± 4.5 Ω
Fuel Sender Resistance -
Full
6 ± 1 Ω
CTS Resistance (77 °F) 29.9 kΩ ± 6%
CTS Resistance (248 °F) 1.22 kΩ ± 2%
Current Draw - Key Off
(Max)
.01 DCA (10 mA)
Stator Leg to Leg
Resistance
Less than 1 Ω
Stator Leg to Ground
Resistance
Open Line (OL / ∞)
Stator Leg Voltage (1300
RPM)
21 VAC ± 25%
Stator Leg Voltage (3000
RPM)
47 VAC ± 25%
Stator Leg Voltage (5000
RPM)
79 VAC ± 25%
Starter Solenoid Terminal
Resistance (77 °F)
2.5 Ω ± 20%
ELECTRICAL
