9.12
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
MASTER CYLINDER INSTALLATION
1. Install brake lines on master cylinder with new seals.
2. Align Brake lines. See Brake Line Clocking, page 9.8.
3. Torque Master Cylinder Banjo Bolt and Brake Switch.
TORQUE
Master Cylinder Banjo Bolt:
15 ft-lbs (20 Nm)
TORQUE
Brake Switch:
15 ft-lbs (20 Nm)
4. Attach the master cylinder to the frame and torque
mounting fasteners to specification.
TORQUE
Master Cylinder Mounting Fasteners:
12 ft-lbs (16 Nm)
5. Attach the master cylinder to the brake pedal lever by
installing the clevis pin and retaining clip.
6. Follow the Brake Fluid Replacement / Brake
Bleeding, page 9.9 procedure.
7. Field test unit for proper braking action before putting
into service. Inspect for fluid leaks and firm brakes.
BRAKE SYSTEM
