3.108
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
HVAC MAINTENANCE
COMPRESSOR DRIVE BELT INSPECTION
1. Position the vehicle on a level surface, place the
transmission in PARK and stop the engine.
2. Tilt the rear cargo box to the upright position.
3. Disconnect the upper duct
q
.
4. Remove the fasteners holding the alternator cover to
the vehicle.
5. Inspect the drive belt for cracks, damage, wear,
separation or oil. Check for debris or buildup in the
drive belt splines. If any of these conditions exist,
replace the belt.
IMPORTANT
ALWAYS use the specified drive belt. Using a non-
specified belt can shorten the belt life.
ENGINE / COOLING / EXHAUST
To Next Page
