9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
3.89
8. Lift the radiator up to remove from the vehicle.
9. Inspect fan blades for damage.
10.Reverse this procedure for installation. Be sure to
properly fill and bleed cooling system as outlined in
this chapter.
e
Upper Radiator Hose
y
To Radiator Fitting
r
Lower Radiator Hose
u
Fan Motor Assembly
t
Recovery Bottle
i
Radiator
RADIATOR FAN REMOVAL
1. Remove Radiator, See Radiator Removal /
Installation, page 3.88
2. Disconnect cooling fan electrical connector.
3. Tilt radiator fan toward the front of the vehicle, then lift
fan up and out.
ENGINE / COOLING / EXHAUST
