RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 503 of 765

Mar 7, 2023

Here is an example of setting an I

C transfer rate where f

MCK

= f

CLK

= 16 MHz.

C Transfer Mode

(Desired Transfer Rate)

CLK

= 16 MHz

Operation Clock (f

MCK

) SDRmn[15:9] Calculated Transfer Rate

Error from Desired Transfer

Rate

100 kHz f

CLK

/2 39 100 kHz 0.0%

400 kHz f

CLK

20 380 kHz 5.0%

Note 1

1 MHz f

CLK

8 0.88 MHz 11.0%

Note 1

Note 1. The error cannot be set to about 0% because the duty ratio of the SCL signal is 50%.

Remark m: Unit number (m = 0), n: Channel number (n = 0, 1), mn = 00, 01
