Removal Procedures
SM 4-55 M126/M127/M128
Replacement
and
Adjustment
4.2.35 USB CABLE MOUNT BRACKET REMOVAL
1. Operator panel keypad.
2. Open the USB cable clamp and remove the USB cable.
3. Remove the screw (A) securing the USB cable mount bracket to the tub assembly.
4.2.36 OPERATOR PANEL SUPPORT REMOVAL
1. Operator panel keypad.
2. Remove the three screws (A) securing the operator panel support to the tub assembly.
 The same steps are performed for both supports.
