M126/M127/M128 4-16 SM
4.2.12 DUPLEX REMOVAL
1. Right side cover ( p.4-66 "Right Side Cover Removal").
2. LVPS/HVPS (
p.4-30)
3. Remove the three screws (A) from the shield.
4. Remove the four screws (B) from the duplex.
5. Lift the duplex slightly, push to the left, and tilt to clear the right side of the printer.
6. Take out the duplex.
